Short Description:

*Input Voltage:AC220-240V 50/60HZ

*Rated Power:3W

*14PCS SMD2835 LEDs inside housing with white color light

*Extra test button, press for manual test

*4 kinds of graphic optional:running man,running man with right arrow,running man with down arrow,running man with left arrow

Advantage: this exit emergency lighting has SELF-DIAGNOSTIC function, details as below:

As soon as AC power is supplied to emergency exit sign light ,the unit will automatically initiate a self-diagnostic test.

Verifies battery failure (disconnection,shorted,voltage drops below than acceptable value), charger board failure, lamps failure and transformer failure at every 5 seconds.Manufacturer  pre-sets all functions-Do not need field adjustment.

*Dual color LED lamp indicator shows the following status:

⑴ Green color         ON / Ready

               Blinking: Testing

⑵ Red color (Service Alert),Service Alert LED Code (Red color LED lamp indicator)

*Built-in NI-MH rechargeable battery provides min. 3hours backup power in the event of a power outage, 4.8V 600MAH, 24 hours charging time after 3 hours discharge, battery overcharge and discharge protection

*CE approval
