China Exit sign emergency lights with SELF-DIAGNOSTIC function LX-705AT manufacturers and suppliers

Exit sign emergency lights with SELF-DIAGNOSTIC function LX-705AT

Short Description:

*Input Voltage:AC220-240V 50/60HZ

*Rated Power:3W

*14PCS SMD2835 LEDs inside housing with white color light

*Extra test button, press for manual test

*4 kinds of graphic optional:running man,running man with right arrow,running man with down arrow,running man with left arrow

Advantage: this exit emergency lighting has SELF-DIAGNOSTIC function, details as below:

As soon as AC power is supplied to emergency exit sign light ,the unit will automatically initiate a self-diagnostic test.

Verifies battery failure (disconnection,shorted,voltage drops below than acceptable value), charger board failure, lamps failure and transformer failure at every 5 seconds.Manufacturer pre-sets all functions-Do not need field adjustment.

*Built-in NI-MH rechargeable battery provides min. 3hours backup power in the event of a power outage, 4.8V 600MAH, 24 hours charging time after 3 hours discharge, battery overcharge and discharge protection

*CE approval

*Wall surface mounting and wall flush mounting available

Send email to us

Product Detail

Product Tags

Regular Info

Model:	LX-705AT	MOQ：	500PCS
lead time：	Regular 25working days since deposit is received	Payment：	T/T
Brand Name：	LXINE	Price Term：	FOB /CNF /CIF
Sample Lead Time：	5 working days after sample cost arrival	Guarantee：	2 years for CE listed lights 1 year for battery
Certification:	CE

Product Parameter

Item No.	In put Voltage	Light Source	AC Power	Battery	Emergency Duration	Material	Lumen	Color
LX-705AT	AC220-240V 50/60Hz	14 Pcs SMD2835 LED	3W	Ni-MH AA 4.8V/600mAh	3 Hours	Fire retardant ABS housing	>8cd/m²	Green
